Concept Turn 105
Concept Turn 105

Concept Turn 105

Giá:
Đã bao gồm VAT
Hoang Quoc Co.,Ltd

Add:  No.7, Lot 5B, Trung Yen New, Cau Giay District, Hanoi City, Vietnam
ĐT      : (84-4)   3831 7421
Fax    : (84-4)  3831 7433
Email : Hoangquoc@hoangquoc.com
  • Infinitely variable main drive
  • 8-station tool changer
  • High-resolution axis motors
  • Pneumatic tailstock
  • Automatic clamping device
  • Robotic Interface for integration into FMS and CIM systems

Travel in X/Y/Z 55 / - / 172 mm
Bar diameter 18 mm
Max. turning diameter: 75 mm
Max. part length with tailstock: 121 mm
Swing over bed: 180 mm
Tool cross-section for outer machining: 12 x 12 mm
Tool cross-section for inner machining:  Ø 16
Rapid motion speeds in X/Y/Z: 5 m/min
Work feed X/Y/Z: 0-5 m/min
Max. speed: 4000 rpm
Spindle nose: EMCO
Max. drive power: 1,9 kW
Max. torque: 14 Nm
Quill stroke: 120 mm
Number of tools: 8
Dimensions (LxWxH): 1135 x 1100 x 1030 mm
Machine weight: 350 kg
